Features:
This machine uses standardized bullets and interchangeable clamping rings, shorten the bullet change-over time and increase productivity;
This machine uses special designed, variable pressure cylinders to clamp the fabics, not only it gives even clamping forces, but also can keep the clamping pressure constant. This will allow fabrics of different thickness and elongation to be molded on this machine;
Hand-wheel and depth gauge is installed on this machine, allowing precious setting of the plunge depth of the bullets. Shorten machine set-up time and improve product quality;
PLC is used to control the safely operation of the machine, features including two-hand safety control, low/high temperature warning, power-outage safety lock;This machine is designed to compile with European/American safety standard, and reinforce the safety of the operators and the factory;
High quality digital temperature controllers are used to control the temperature of the molds, resulting in fast reaction and high accuracy. Thermo-insulation material is used to maintain the heat in the lower heater, making this machine consuming less electricity and environmental friendly.

Parameter:
Power:AC220V/4.4KW
Compressed air:0.4~0.8Mpa
Molding time:0~999s
Bullet diameter:Ø70mm~Ø175mm,Ø70mm~Ø220mm
External dimensions:760mm×760mm×2200mm
Weight:295kg
